Mercury 40 Service Manual

CARBURETOR
90-828631R3 MARCH 1999 Page 3B-19
5. Remove carburetor unit from intake manifold.
53679
6. Remove dowel pins.
7. Remove insulator from carburetor by prying near the plugs.
53679
a
b
c
c
a
a-Dowel Pin (2)
b-Insulator
c-Plug (2)

Mercury 40 Specifications

General

Horsepower	40 hp
Starting System	Electric
Steering	Remote
Fuel Induction System	EFI (Electronic Fuel Injection)
Shaft Length	20"
Full Throttle RPM Range	6000
