Mercury 40

CYLINDER BLOCK/CRANKCASE
Page 4B-590-828631R3 MARCH 1999
Crankshaft
REF.
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb-in. lb-ft Nm
1
1 CRANKSHAFT (NON-BIGFOOT)
1
1 CRANKSHAFT (BIGFOOT)
2 1 OIL SEAL
3 1 OIL SEAL
4 4 CONNECTING ROD
5 8 BOLT 150 12.5 17
8 BEARING (BROWN)
6 8 BEARING (BLACK)
8 BEARING (BLUE)
7
4 PISTON (STANDARD)
7
4 PISTON (.5MM O/S)
8
4 PISTON RING (TOP) (STANDARD)
8
4 PISTON RING (TOP) (.5 MM O/S)
9 4 PISTON RING (SECOND)
10 4 PISTON OIL RING
11 4 PISTON PIN
12 8 RETAINER
