Mercury 40 Service Manual

CLAMP/SWIVEL BRACKETS & DRIVESHAFT HOUSING
90-828631R3 MARCH 1999 Page 5A-3
Transom Bracket
REF.
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb-in. lb-ft Nm
1
1 TRANSOM BRACKET (PORT)(BLACK)
1
1 TRANSOM BRACKET (PORT)(GRAY)
2 1 GREASE FITTING (NON-BIGFOOT)
3 1 GROOVE PIN
4
1 TRANSOM BRACKET (STBD.)(BLACK)
4
1 TRANSOM BRACKET (STBD.)(GRAY)
5
1 TILT LOCK LEVER (BLACK)
5
1 TILT LOCK LEVER (GRAY)
6 1 SPRING
7 1 NYLINER
8 1 SPRING
9
1 KNOB (BLACK)
9
1 KNOB (GRAY)
10 1 GROOVE PIN
11 2 WASHER
12
1 ANCHOR BRACKET (BLACK)
12
1 ANCHOR BRACKET (GRAY)
13 1 ANODE ASSEMBLY
14 2 SCREW (M6 x 25) 60 6.8
15 2 WASHER
16
5 SCREW (30 MM)
16
1 SCREW (35 MM)
17 4 LOCKWASHER
18 2 NUT
19 1 TILT PIN ASSEMBLY NON POWER TRIM
20 1 SPRING
21 1 TILT TUBE
22 2 NUT Tighten nut to 32 lb-ft
and then back off 1/4
turn
23 1 SEAL KIT
24 1 O RING NON-HANDLE
25 1 SPACER
26 2 CLIP
27 1 C-WASHER POWER TRIM
28 1 SCREW Drive Tight
29 4 SCREW Drive Tight
30 4 WASHER Drive Tight
31 4 NUT
32 1 LINK
33 1 TILT LEVER
34 1 BUSHING NON POWER TRIM
35 1 WASHER
36 1 WAVE WASHER
37 1 TILT KNOB
38 1 SCREW (.375-16 x .62) 220 18.3 24.9
39 2 SCREW (M10 x 40)
40
2 WASHER
41
2 NUT
42
1 DECAL-Tilt Lock
