Mercury 40 Service Manual

CLAMP/SWIVEL BRACKETS & DRIVESHAFT HOUSING
90-828631R3 MARCH 1999 Page 5A-5
Swivel Bracket
REF.
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb-in. lb-ft Nm
1 1 LINK ROD
2 1 SCREW (1-1/2 IN.) 20 27.0
3 1 WASHER NON HANDLE
4 2 WASHER
5 2 NUT (.375-24) 120 13.5
6 1 PUCK
7 1 BUSHING
8
1 SWIVEL BRACKET (BLACK)
8
1 SWIVEL BRACKET (GRAY)
9 2 BEARING
10 2 GREASE FITTING
11 1 DECAL-Co-Pilot
12 1 DECAL-Serial Overlaminate
13 1 BUSHING (LOWER)
14 1 SEAL
15
1 SCREW (M8 x 10) (HANDLE)
15
1 SCREW (M8 x 25) NON HANDLE
16 1 SEAL
17 2 BUSHING (NON-BIGFOOT)

Mercury 40 Specifications

General

Horsepower	40 hp
Starting System	Electric
Steering	Remote
Fuel Induction System	EFI (Electronic Fuel Injection)
Shaft Length	20"
Full Throttle RPM Range	6000
