CLAMP/SWIVEL BRACKETS & DRIVESHAFT HOUSING
90-828631R3 MARCH 1999 Page 5A-7
Driveshaft Housing
REF.
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb-in. lb-ft Nm
1 1 SEAL–water tube
2
1 DRIVESHAFT HOUSING (NON-BIGFOOT) (BLACK)
2
1 DRIVESHAFT HOUSING (NON-BIGFOOT) (GRAY)
3
1 DRIVESHAFT HOUSING (BIGFOOT) (BLACK)
3
1 DRIVESHAFT HOUSING (BIGFOOT) (GRAY)
4 1 EXHAUST TUBE RETAINER
5 1 PLATE BIGFOOT
6 1 SCREW (M10 x 25)
7 8 SCREW–Adaptor Plate 336 28 38
8 5 SCREW (M8 x 1.25 x 45) 336 28 38
9 1 BUMPER
10 1 DRAIN PLUG 210 17.5 23.5
11 1 GASKET
12 2 BUMPER
13 1 GROMMET
14
1 STUD (NON-BIGFOOT)
14
1 STUD (BIGFOOT)
15 1 WASHER
16 1 NUT 40 54.5
17 1 WATER TUBE
18 1 GUIDE
19 4 SCREW
20 4 WASHER
21 1 SPEEDOMETER PICK UP ASSEMBLY
22 1 CONNECTOR (STRAIGHT)
23 1 FITTING
24 1 SPACER BIGFOOT
25 1 COUPLING
26 1 BUSHING

Mercury 40 Specifications

General

Horsepower	40 hp
Starting System	Electric
Steering	Remote
Fuel Induction System	EFI (Electronic Fuel Injection)
Shaft Length	20"
Full Throttle RPM Range	6000
