Mercury 40 Service Manual

CLAMP/SWIVEL BRACKETS & DRIVESHAFT HOUSING
90-828631R3 MARCH 1999 Page 5A-11
Steering Arm
REF.
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb-in. lb-ft Nm
1 2 NUT
2 1 STRAP
3 2 MOUNT
4 1 BUMPER
5 1 BUMPER (BIGFOOT)
6 1 RETAINING RING
7
1 STEERING ARM (BLACK)
7
1 STEERING ARM (GRAY)
8 1 BRACKET
9 1 TAB WASHER NON HANDLE
10 2 SCREW (M10 x 1.5 x 30) 32.5 44
11 2 SCREW (M12 x 1.75 x 154) 50 68
12 2 WASHER (BIGFOOT)
13 1 SPACER
14
1 SWIVEL TUBE (NON-BIGFOOT)
14
1 SWIVEL TUBE (BIGFOOT)
15 1 GROUND STRAP
16 1 GROUND STRAP
17 2 SCREW (M10 x 1.5 x 105) 32.5 44
18 2 WASHER (BIGFOOT)
19 1 BRACKET
20 3 SCREW(SELF–TAPPING) Drive Tight
21 2 NUT
22 1 NUT (.375-24)
23 1 LEVER–Co-Pilot
24 1 WASHER
25 1 ROD (THREADED) HANDLE
26 1 BRACKET PLATE
27 1 DISC
28 1 PLATE
29 1 DISC
30 2 SCREW (Hex Shoulder) 70 8.0

Mercury 40 Specifications

General

Horsepower	40 hp
Starting System	Electric
Steering	Remote
Fuel Induction System	EFI (Electronic Fuel Injection)
Shaft Length	20"
Full Throttle RPM Range	6000
