MANUAL TILT ASSIST
90-828631R3 MARCH 1999 Page 5D-3
Manual Tilt Components
REF.
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb-in. lb-ft Nm
1
1 SHOCK ROD ASSEMBLY 45 61
1
1 SHOCK ROD ASSEMBLY (BEACHING)
2 1 MEMORY PISTON ASSEMBLY
3 1 O RING REBUILD KIT-Cylinder
4 2 O RING
5 1 CYLINDER ASSEMBLY
6 1 SCREW AND SEAL KIT
7 1 ACCUMULATOR ASSEMBLY 35 47
8 1 VALVE BODY ASSEMBLY
9 1 CAM KIT
10 1 VELOCITY VALVE KIT 75 6.2 8.5
11 1 CHECK SYSTEM REPAIR KIT 75 6.2 8.5
– 1 O RING KIT
12 2 PIN
13 2 GROOVE PIN
A – Torque cylinder cap to 45 lb-ft (61 Nm)
B – Torque Accumulator to 35 lb-ft (47 Nm)
C – Torque Velocity Valve to 75 lb-in. (8.5 Nm)
D – Torque Transfer Valve Plug to 75 lb-in. (8.5 Nm)
E – Torque Screw to 100 lb-in. (11 Nm)
F – Torque Shock Piston to 90 lb-ft (122 Nm)
