BIGFOOT GEAR HOUSING
Page 6B-12 90-828631R3 MARCH 1999
Removal
WARNING
To prevent accidental engine starting, remove (and isolate) spark plug leads from
spark plugs before removing gear housing.
1. Remove (and isolate) spark plug leads from spark plugs.
2. Shift engine into forward gear.
3. Tilt engine to full “Up” position.
4. Remove 4 fasteners.
5. Remove locknut and washer.
6. Remove gear housing.
53992
a
b
a-Fasteners (2 Each Side)
b-Locknut and Washer
To Next Page
