Mercury 40 Service Manual

THROTTLE/SHIFT LINKAGE
90-828631R3 MARCH 1999 Page 7A-5
Linkage (Bigfoot)
REF.
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb-in. lb-ft Nm
1 1 SCREW (M8 x 70) 100 11.3
2 1 SCREW (M6 x 55)
3 1 NUT
4 1 CAP
5 1 RETAINER
6 1 THROTTLE LEVER
7 1 BUSHING
8 1 RETAINER
9 1 SHIFT LEVER
10 1 BRACKET
11 1 LATCH
12 2 SCREW (M6 x 16) 75 8.5
13 2 SLEEVE
14 1 SHIFT ROD
15 1 GUIDE-Shift Rod
16 1 SHIFT LINK
17 2 NYLINER
18 2 WASHER
19 1 NUT
20 1 COTTER PIN
21 1 SHIFT SHAFT LEVER
22 1 BUSHING
23 1 THROTTLE CAM
24 1 SPACER
25 1 WASHER
26 1 SCREW (M5 x 16) 75 8.5

Mercury 40 Specifications

General

Horsepower	40 hp
Starting System	Electric
Steering	Remote
Fuel Induction System	EFI (Electronic Fuel Injection)
Shaft Length	20"
Full Throttle RPM Range	6000
