Mercury 40 Service Manual

TILLER HANDLE
90-828631R3 MARCH 1999 Page 7B-3
Tiller Handle
REF.
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb-in. lb-ft Nm
1 1 COVER KIT
2 1 PULLEY
3 1 CASE
4 1 SCREW (10-16 x 1/2 IN. Self Tapping) 20 2.5
5 1 THROTTLE CABLE (30-1/2 IN.)
6 1 THROTTLE CABLE (41-1/2 IN.)
7 1 SLEEVE
8 2 SCREW (M8 x 25) 16.5 22.5
9
1 COVER (BLACK)
9
1 COVER (GRAY)
10 1 BUSHING
11
1 ARM–Steering Handle (BLACK)
11
1 ARM–Steering Handle (GRAY)
12 1 RETAINER
13 1 SCREW (M5 x 16) 35 4.0
14 1 SCREW (M6 x 25)
15 1 LOCK–Throttle
16 1 SPRING
17 1 KNOB–Throttle
18 1 CLIP
19 1 SWITCH (START)
20 1 HOUSING
21 1 DECAL-Start
22 1 TILLER TUBE
23 1 DECAL
24 1 HANDLE–Throttle
25 1 GRIP
26 1 SWITCH (STOP)
27 1 SCREW (M5 x 12)
28 1 WASHER
29 1 ALARM
30 2 CLIP
31 1 STA-STRAP
32 1 DECAL-Shift
33 1 SWITCH (STOP)
34 1 LANYARD SWITCH
35 1 RETAINER
36 1 SCREW (M8 x 35)
37 1 SHIFT HANDLE
38 1 BUSHING
39 1 SHIFT ROD
40 1 WASHER
41
1 BRACKET–Tiller (BLACK)
41
1 BRACKET–Tiller (GRAY)
42 1 WAVE WASHER
43 1 BUSHING
44 1 WASHER
45 1 CONDUIT
