Section 3 - On the Water
Page 40 90-866938081 MAY 2009
Joystick Input Boat Response
Movement
(shown from light gray to dark gray)
24705
Boat moves forward
25928
24706
Boat moves aft
25927
24707
Boat moves to starboard
without rotating
25929
24708
Boat moves to port
without rotating
25931
