Section 5 - Maintenance
Page 100 90-866938081 MAY 2009
4. Inspect the fluid level, which should be at the full‑cold mark.
a - Cap and dipstick
b - Full‑cold mark
c - Low‑cold mark
d - Add
5. If the level is low, see Filling.
6. If the level is correct, insert the cap and dipstick into the neck of the reservoir. Push
down and turn the reservoir cap in the close direction.
a - Cap and dipstick
b - Open direction
c - Close direction
Filling
1. Using a clean, lint‑free cloth, wipe the dirt and debris away from the cap and exterior
of the steering actuator and trim fluid reservoir.
NOTE: The direction to rotate the cap to open or close is imprinted on the top of the cap.
