Section 3 - On the Water
Page 42 90-866938081 MAY 2009
Joystick Input Boat Response
Movement
(shown from light gray to dark gray)
24712
Boat moves diagonally
forward and to the port
without rotating
25925
24713
Boat rotates clockwise
25921
24714
Boat rotates counter
clockwise
25920
24715
Boat moves diagonally
forward and to the
starboard while rotating
clockwise
25916
