Metor 6M - Setting Zone Sensitivity; Selecting the Detecting Program

Metor 6M PAGE 41
Installation and Operating Manual
92102916 REV 5 8. CALIBRATION
Setting Floor Level Sensitivity using Auto Floor Sensitivity Function (recommended)
1. Select Auto Floor Sensitivity function.
2. Walk through the WTMD with a test object attached to your ankle. Walk
through the gate at least two different manners: by placing down the foot with
the test object at the middle of the gate (Fig. 1), and by swinging the foot
through the gate (Fig. 2). After each pass the display shows the total number of
walks, the zone detecting the object better and its sensitivity value needed to
cause an alarm on the last walk.
Wait a couple of seconds between successive walks. If necessary repeat with
another test object. Walk in the direction of intended use of the WTMD. In the case
of bidirectional use walk in both directions.
When you have finished walking press to accept the new floor level
sensitivity setting. A minimum of three (3) walks is needed. If you choose to exit
without accepting the new sensitivity setting, press . If there are no walks in
five (5) minutes, the WTMD will return to the normal operation mode without
changing the floor level sensitivity.
In case the detection program is not suited for the test object and the required
sensitivity would be over the set range a warning is given. Exit auto floor
sensitivity mode and choose a different program.
1 METAL DETECTION
PARAMETERS
1.1 SENSITIVITIES
1.1.1 SENSITIVITY
1.2 PROGRAM
1.1.2 ZONE SENSITIVITITIES
1.1.3 AUTO SENSITIVITY
1.1.4 AUTO FLOOR SENSITIVITY
OK
OK
C
