Page 122
Error message Meaning of the error message Measures
Main
index
Sub
index
3 Motor overtemperature
(analogue): short circuit
Check the connecting cables of the temperature
sensor (short circuit).
Check the parameterisation of the short-circuit
monitoring system (threshold value).
04 0 Power module overtemperature Plausible temperature indication?
Check the installation conditions. Fan filter mats
dirty?
Device fan defective?
1 DC bus circuit overtemperature
05 0 Failure of internal voltage 1 Disconnect the device from the entire periphery
and check whether the error is still present after
a reset.
If the error is still present, return the device to
your sales partner.
1 Failure of internal voltage 2
2 Driver supply failure
3 Undervoltage of the digital I/Os Check the outputs for short circuits or specific
load.
If necessary, contact the Technical Support.
4 Overcurrent of the digital I/Os
5 Technology module supply
voltage failure
Technology module defective?
Replace the technology module.
If necessary, contact the Technical Support.
6 X10, X11 and RS232 supply
voltage failure
Check the pin assignment of the connected
peripheral equipment.
Check the connected peripheral equipment for
short-circuits.
7 Safety module internal voltage
failure
Safety module defective?
Replace the safety module.
If the error persists, please send the servo drive
to our sales partner.
8 Failure of internal voltage 15 V Please return the device to our sales partner.
9 Faulty encoder supply
06 0 Short circuit in the power output
stage
Motor defective?
Short circuit in the cable?
Power output stage defective?
Product Manual „Servo drives ARS 2100 SE“ Version 5.0
