Metronix ARS 2100 SE Series User Manual

Page 130
Error message Meaning of the error message Measures
Main
index
Sub
index
30 0 Internal conversion error Please contact the Technical Support.
31 0 Motor I²t Motor blocked?
Check the power rating of the drive.
1 Servo drive I²t Check the power rating of the drive package.
2 PFC I²t Check the power rating of the drive.
Select operation without PFC?
3 Braking resistor I²t Braking resistor overloaded.
Use external braking resistor?
4 I²t active power overload Reduce the active power of the drive.
32 0 DC bus circuit charging time
exceeded
Bridge for the internal brake resistor installed?
Check the connection of the external braking
resistor.
If necessary, contact the Technical Support.
1 Undervoltage for active PFC Check whether the power supply complies with
the nominal data.
5 Brake chopper overload
The DC bus circuit could not be
discharged.
Check the ON/OFF cycles.
6 DC bus circuit discharge time
exceeded
Bridge for the internal brake resistor installed?
Check the connection of the external braking
resistor.
If necessary, contact the Technical Support.
7 No power supply for the
controller enable signal
No DC bus circuit voltage?
Check the power supply.
If necessary, contact the Technical Support.
8 Power supply failure during the
controller enabling process
Check the power supply.
9 Phase failure
33 0 Following error, encoder
emulation
Check the settings of the incremental encoder
emulation (number of lines).
If necessary, contact the Technical Support.
Product Manual „Servo drives ARS 2100 SE“ Version 5.0
