Error message Meaning of the error message Measures
Main
index
Sub
index
6 Error in cross-comparison for
processors 1 - 2
Cause: Timeout during cross-comparison (no
data) or cross-comparison faulty (data
for µC1 and µC2 are different).
 Error in cross-comparison for digital
I/O.
 Error in cross-comparison for
analogue input.
 Error in cross-comparison for
internal operating voltage
measurement (5 V, 3.3 V, 24 V) and
reference voltage (2.5 V).
 Error in cross-comparison for
SIN/COS angle encoder analogue
values.
 Error in cross-comparison for
programme sequence monitoring.
 Error in cross-comparison for
interrupt counter.
 Error in cross-comparison for input
map.
 Error in cross-comparison for
violation of safety conditions.
 Error in cross-comparison for
temperature measurement.
Action: This is an internal error in the module
that should not occur during operation.
 Check the operating conditions
(temperature, air humidity,
condensation).
 Check the EMC wiring as specified
and screening design; are there any
external interference sources?
 Safety module may be faulty – is
error eliminated after replacing the
module?
 Check whether new firmware for the
servo drive or a new version of the
safety module is available from the
manufacturer.
Product Manual „Servo drives ARS 2100 SE“ Version 5.0
