Metronix ARS 2100 SE Series User Manual

Page 151
Error message Meaning of the error message Measures
Main
index
Sub
index
59 1 FSM: Fail-safe mode
supply/safe pulse inhibitor
Cause: Internal error in module in failsafe
supply circuit section or in the driver
supply for the upper and lower
switches.
Action: Module faulty, replace.
2 FSM: Logic failure /
intermediate circuit
Cause:
 Reference voltage 2.5 V outside
tolerance.
 Logic supply overvoltage +24 V
detected.
Action: Module faulty, replace.
3 FSM: Error internal power
supply
Cause: Voltage (internal 3.3 V, 5 V, ADU
reference) outside the permissible
range.
Action: Module faulty, replace.
4 FSM: Error management, too
many errors
Cause: Too many errors have occurred
simultaneously.
Action:
 Clarify: What is the status of the
installed safety module - does it
contain a valid parameter set?
 Read out and analyse the
permanent event memory of the
basic device via Metronix
ServoCommander®
 Eliminate error causes step by step.
 Install safety module with “delivery
status” and perform commissioning
of basic device.
 If this is not available: Set factory
settings in the safety module, then
copy data from the basic device and
perform complete validation. Check
whether the error occurs again.
5 FSM: Log file - write error Please contact the Technical Support.
6 FSM: Parameter set - save
error
Please contact the Technical Support.
Product Manual „Servo drives ARS 2100 SE“ Version 5.0
