Meva MevaLite - ML-Outside Corner

ML-70
MevaLite
Wall formwork
Technical Instruction Manual - Product list / June 2022
1'-6"
1
1
2
"
5'-8
3
4
"
1
1
2
"
1'-6"
9'
1'-6"
1
1
2
"
2'-8
3
4
"
1
1
2
"
1'-6
"
6'
2"
1
1
2
"
3'-5"
1
1
2
"
2"
4'
2"
1
1
2
"
2'-5"
1
1
2
"
2"
3'
22-505-10 ................ML-outside corner 9’ ...........................................................20.5
23-505-20 ................ML-outside corner 6’ ...........................................................13.7
23-505-30 ................ML-outside corner 4’ .............................................................9.5
23-505-40 ................ML-outside corner 3’ .............................................................7.5
4 1/4”
4 1/4”
ML-outside corner
aluminum, together with MevaLite-panels and
EA-assembly locks it provides a solid outside
corner assembly for 90° angles with high
resistance to tensile force.
Ref.-No. Description / Application lb
