Meva MevaLite - Alignment Rails; Corner Bracket 40;60

ML-74
MevaLite
Wall formwork
Technical Instruction Manual - Product list / June 2022
2-500-2331040 ....................Steel rail 12' ...........................................................155.0
2-500-2331035 ....................Steel rail 8' .............................................................80.0
2-500-2331030 ....................Steel rail 6' .............................................................61.0
2-500-2331020 ....................Steel rail 4' .............................................................44.0
2-500-2251010 ....................Steel rail 3' .............................................................29.0
galvanized; to brace panel joints for gang
forming, to support fillers and to build
bulkheads. Is attached to formwork with flange
screws.
Alignment rails
1 1/2”
4”
4”
4”
12’
5 1/4”
6’
4’
12’-5 1/4”
6’-5 1/4”
4’-5 1/4”
3’
4”
2” 2”
2”
2”
2”
2”
2”
2”
5 1/4”
5 1/4”
1 1/2”
1 1/2”
1 1/2”
1 1/2”
2”
2”
4”
5 1/4”
8’
8’-5 1/4”
29-402-25 ................Corner bracket 40/60 ..........................................................20.9
Corner bracket 40/60
galvanized; to reinforce corner applications.
Ref.-No. Description / Application lb
4”
1’-3 3/4”
Ø 15/16”
4 1/4”
1 1/2”
Ø 15/16”
1’-11 5/8”
Ref.-No. Description / Application lb
