MevaLite
ML-85
Wall formwork
Technical Instruction Manual - Product list / June 2022
Shoe plate 23
galvanized; to anchor forms to the supporting
structure.
2-500-2331196 ........Shoe plate 23 ........................................................................4.7
Ref.-No. Description / Application lb
3 1/8”
4”
6 7/8”
Ø 7/8”
Foundation spanner ML
galvanized; to connect the foundation tape to
MevaLite panels; it serves as bottom tie when
panels are assembled in horizontal position.
Two (2) foundation spanners are required per
tieing position.
29-307-85 ................Foundation spanner ML .........................................................3.7
Ref.-No. Description / Application lb
