Meva MevaLite - Push-Pull Prop R 160; Push-Pull Prop R 250

MevaLite
ML-83
Wall formwork
Technical Instruction Manual - Product list / June 2022
Push-pull prop R 160
galvanized; high tensile and compression
strength, for aligning formwork.
Articulated foot plate and formwork-prop
connector must be ordered separately.
Adjustment range: 4’-6” to 6’-6”.
29-109-40 ................Push-pull prop R 160 ...........................................................24.3
Ref.-No. Description / Application lb
Adjustment range 4’-6” to 6’-6”
8 1/8”
Push-pull prop R 250
galvanized; high tensile and compression
strength, for aligning formwork.
Articulated foot plate and formwork-prop
connector must be ordered separately.
Adjustment range: 6’-3” to 10’-5”.
29-109-60 ................Push-pull prop R 250 ...........................................................40.8
Ref.-No. Description / Application lb
Adjustment range 6’-3” to 10’-5”
8 1/8”
