ML-80
MevaLite
Wall formwork
Technical Instruction Manual - Product list / June 2022
Support 800 for guard-
railing post
galvanized; allows plugging in of all MEVA
guard-railing posts. The support 800 is
mounted to MEVA wall-formwork panels by
using a flange screw 18.
The angle between wall formwork and guard-
railling post is about 15°.
Not for use on horizontal panels!
Guard-railing post and flange screws 18 must
be ordered separately.
29-108-50 ................Support 800 for guard-railing post ......................................22.5
Ref.-No. Description / Application lb
41 3/16"
7 1/4"
5 3/4"
4"
3"
13"
2 9/16"
Side railing
galvanized; for walkway brackets. 29-108-20 ................Side railing 90/100 ..............................................................27.1
Ref.-No. Description / Application lb
42”
49”
43 1/2”
50”
31 5/8”
35 1/2”
