47
Take out the upper fixing screw of the back shock absorber
(set screw when assembling 40N/m)
With damaged wood scissors and an adjustable thermal scrapper
(maximum heating temperature 60°), unglue the floor from the side
frame).
Unglue very carefully the apron cover from the frame
Take care not to damage the dash panel cover
because this one is weaker than the floor.
Remove the 2 upper fixing screws of the engine cable.
(set screw when assembling 22N/m)
Remove the 2 low fixing screws of the engine craddle
(set screw when fitting again 22N/m)
