Milltronics HydroRanger Plus - Page 21

RELAYS
Connect, alarm, pump, and/or control devices, to the HYDRO+ relays, after RUN
mode operation is verified. (See for connection details).
Wall Mount
See for relay ratings.
Relays are shown in the alarm on / pump off / power off / de-energized position.
SPECIFICATIONS
APPLICATIONS
Rack or Panel Mount
com
n. c.
n. o.
com
n. c.
com
n. c.
n. o.
n. c.
n. o.
n. o.
com
n. c.
n. o.
relay 5
relay 2
relay 1
relay 4
relay 3
com
INSTALLATION
PL-507 21
