mA OUTPUT
The HYDRO+ mA output may be used to operate a variety of control/monitoring
devices (1000 Ω max. load), providing 300 Vac continuous isolation.
mA output to customer instrumentation, ground shield at one end only.
mA INPUT
If HYDRO+ features are required based upon measurements obtained from another
level monitor, connect the level monitor mA output, to the HYDRO+ mA input
terminals. Most HYDRO+ display, relay and mA output features may be used based
upon the measurements provided by the auxiliary level monitor.
If this feature is used, refer to Transducer (P004) and mA Input
Parameters (P250, P251, and P252).
mA input proportional to level, ground shield at one end only.
PARAMETERS
Rack or Panel Mount
mA out
Wall Mount
mA out
Rack or Panel Mount
Wall Mount
mA input
mA input
PL-507 22
