Visual Inspection Checklist Periodic Maintenance
3 - 4 046-001141-00 A5/A3™ Service Manual
3.5 Visual Inspection Checklist
1. Verify that the anesthesia system has no physical damage that would prevent operation.
2. Verify that the breathing circuit and Pre-pak absorber canister are present.
3. Verify that the vaporizers are filled but not overfilled.
4. Verify that the Preoperative Checkout List is attached.
5. Verify that the tank wrench is attached.
6. Verify that the transfer tube of the AGSS is not damaged. Drain any moisture.
7. Verify that the AC power cord is not damaged.
3.6 List of Periodic Maintenance Parts to be
Replaced and Checked
The following table lists the parts to be checked or replaced periodically inside the consumable parts
kits. The replacement date starts from the date when the machine is assembled. The filter (part
number:082-000423-00) is not needed for FDA A3/A5.
No. Consumable Part Amount
12
Month
36
Month Part Number
1 Lithium-ion battery
2 (A5)
1 (A3)
Check Replace 115-018012-00
2
Cell battery Lithium 3V35mAh
D12.5*2.0 (for main control board)
1 Check Replace M05-010R03---
3 Bellows assembly 1 Check Replace 0601-30-78968
4 O-ring (for airway pressure gauge) 1 Check Replace
082-000653-00(Old)
082-001524-00(New)
5 O-ring 15.54X2.62 (for bag arm) 2 Check Replace 082-000673-00
6 Gasket, bellows canister base 1 Replace Replace 049-000243-00
7 O-ring 15.54X2.62 (for O2 cell cover) 1 Replace Replace 082-000673-00
8 O-ring 14X2.65 (for Vaporizer mount) 6 Replace Replace 082-000934-00***
9 AGSS filter 1 Clean Replace 082-000506-00
10
O-ring 8.5X2 (for rotating block of
breathing circuit)
2 Check Replace 082-000665-00
11
O-ring 4.7X1.8 (for rotating block of
breathing circuit)
4 Check Replace 082-000667-00
12
O-ring 16X2 (for rotating block of
breathing circuit)
2 Check Replace M6M-010058---
13
O-ring 27X1.5 (for Check valve
dome)
2ReplaceReplace
082-000626-00(Old)
082-001501-00(New)
14 O-ring 20X1.5 (for Check valve) 2 Replace Replace
082-000628-00(Old)
082-001503-00(New)
15
O-ring 6X1 (for Auto/Manual
ventilation switch)
2 Check Check 082-000669-00
16
O-ring 23.47X2.95 (for Water
Collection Cup)
1ReplaceReplace
082-000629-00(Old)
082-001504-00(New)
17 CO2 Absorber Hose 1 Check Replace 049-000146-00
