Mindray A5 Service Manual

Ventilator Control and Drive Theory of Operation
1 - 70 046-001141-00 A5/A3™ Service Manual
1.7.4 Infrared Communication Board
FIGURE 1-59 Infrared Communication Board, Top View
FIGURE 1-60 Infrared Communication Board, Bottom View
7 BC2 Battery In-position Signal
8GND Ground
PIN NAME FUNCTION

Mindray A5 Specifications

General

Type	Anesthesia Machine
Brand	Mindray
Model	A5
Power Supply	100-240 V AC, 50/60 Hz
Ventilation Modes	SIMV, PSV
Flowmeters	O2, N2O, Air
Vaporizer Capacity	Up to 3 vaporizers
Safety Features	O2 failure protection, low pressure alarm
Gas Module	Optional integrated gas module
Integrated Air Compressor	Optional
Patient Monitoring	Integrated monitoring with optional modules
