Mindray A5 Service Manual

System Calibration Calibration
4 - 68 046-001141-00 A5/A3™ Service Manual
FIGURE 4-85
FIGURE 4-86
5. Turn the O2, AIR and N2O needle valves to the maximum positions. Turn the AIR resistor on the
pneumatic resistor block assembly to cause the AIR flow to fall within 15 to 15.5 L/min.
N2O Resistor

Mindray A5 Specifications

General

Type	Anesthesia Machine
Brand	Mindray
Model	A5
Power Supply	100-240 V AC, 50/60 Hz
Ventilation Modes	SIMV, PSV
Flowmeters	O2, N2O, Air
Vaporizer Capacity	Up to 3 vaporizers
Safety Features	O2 failure protection, low pressure alarm
Gas Module	Optional integrated gas module
Integrated Air Compressor	Optional
Patient Monitoring	Integrated monitoring with optional modules
