Mindray A5 Service Manual

Electrical and Pneumatic Connections Theory of Operation
1 - 14 046-001141-00 A5/A3™ Service Manual
S/N From To P/N
25 Total Flow Meter Vaporizer Manifold M6G-020014---
26 Back Pressure Regulator Total Flow Meter M6G-020014---
27 N2O Flow Sensor Gas Mixer 082-000524-00
28 Air Flow Sensor Gas Mixer 082-000520-00
29 O2 Flow Sensor Gas Mixer 082-000522-00
30 ORC Assembly ORC Assembly 082-000524-00
31 Restrictor Assembly Air Flow Sensor 082-000520-00
33 ORC Assembly Y2 082-000522-00
34 N2O Cylinder Yoke Y1 082-000662-00
35 Y1 N2O Regulator 082-000662-00
36 Air Cylinder Yoke Y1 082-000517-00
37 Y1 Air Regulator 082-000517-00
38 Y1 Y1 082-000521-00
39 O2 Pipeline Pressure Gauge O2 Pipeline Assembly 082-000523-00
40 N2O Pipeline Pressure Gauge N2O Pipeline Assembly 082-000516-00
41 Air Pipeline Pressure Gauge AIR Pipeline Assembly 082-000518-00
42 O2 Regulator Y2 082-000522-00
43 Y2 System Switch 082-000522-00
44 Y2 O2 Flush Button 082-000522-00
45 System Switch O2 Needle Valve 082-000522-00
46 Y2 ORC Assembly 082-000522-00
47 Y1 O2 Regulator 082-000521-00
48 N2O Regulator ORC Assembly 082-000516-00
49 ORC Assembly N2O Needle Valve 082-000516-00
50 Air Regulator Y2 082-000520-00
51 Y2 Air Needle Valve 082-000520-00
52 O2 Flush Button Common Gas Outlet 082-000522-00
53 Vaporizer Manifold Common Gas Outlet M6G-020014---
54 Y1 Air Pipeline Assembly 082-000517-00
55 Exhalation Valve Assembly Gas Reservoir 082-000522-00
56 Y2 Y2 082-000522-00
57 Y2 Auxiliary O2 Assembly 082-000522-00
58 Gas Mixer Back Pressure Regulator M6G-020014---
59 Y1 O2 Pipeline Assembly 082-000521-00
60 O2 Cylinder Yoke Y1 082-000521-00
61 Y1 Y1 082-000521-00
62 Y1 N2O Pipeline Assembly 082-000662-00
63 Y1 Exhalation Valve Assembly 082-000521-00
64 Auxiliary Air Assembly Y2 082-000520-00
65 Auxiliary O2 Assembly Y2 082-000522-00
66 Y2 Auxiliary Gas Outlet M6G-020026---
67 Y2 Auxiliary Air Assembly 082-000520-00
