Disassemble the Assemblies
Repair and Disassemb
ly
6 - 18
046-001141-00
A5/A3™ Service Manual
Remove the Br
eak
er Assembly
1.
Remove the r
e
ar panel assembly of the har
dware box.
2.
Unscrew the
breaker screws
to remov
e each brea
ker.
Th
e A5 has five (5)
breakers. The A3 has
three (3) bre
akers.
FIGURE 6-33
357
359
