Product Specifications MPAN Specifications
BP10 Operator’s Manual A - 5
A.6 MPAN Specifications
A.6.1 Technique Specification
A.6.2 Wireless Functions
■ BP10 transmits measurement information (e.g. real-time measurement status,
results, NIBP countdown) to TD60/TM80.
■ TD60/TM80 transmits control information (e.g. NIBP start/stop, NIBP STAT) to BP10.
A.6.3 Function Specifications
Protocol
Bluetooth low energy 4.0
Modulation mode
GFSK
Operating frequency
2402 MHz to 2480 MHz
Channel spacing
2 MHz
Wireless baud rate
(data rate)
1 Mbps
Output power
(transfer power)
≤ 2.5 mW
Data Security
Private protocol
Data integrity
Code error ≤ 1%
Transmission distance
Distinct vision distance between BP10 and TD60/TM80 is
greater than or equal to 3 m.
System capacity
Five pairs of BP10 and TD60/TM80 can communicate in 10 m
2
space at the same time.
Resistance to wireless
interference
The MPAN communication function is normal when the
distance between the following interfering devices and the
TD60/TM80 or BP10 is as follow:
■ greater than 1 m for microvave ovens.
■ greater than 0.2 m for cellular mobile communcation
networks, Wi-Fi devices, interphones, or cordless phones.
Communication
interruption prompt
message
After the MPAN communication is interrupted, BP10 shows
prompt message.
