Mindray DC-30 Service Manual

8-4 Options Installation
8.2 Installation of Hardware Optional Function
Hardware configuration list that the product supports is displayed below:
No.
Material
Description
Material No.
Material and pictures
Installation
reference
1.
Battery Kit
115-012080-00
7.4.12.5
2.
4D board
assembly
115-038183-00
7.4.6.5
3.
ECG Upgrade
Kit(AHA Lead)
115-038753-00
7.4.6.6
Remark:
connect the
ECG lead
to ECG port
after
upgrade.
4.
ECG Upgrade
Kit(IEC Lead)
115-038752-00

Mindray DC-30 Specifications

General

DICOM	Yes
Hard Drive	500 GB
Continuous Wave Doppler	Yes
Tissue Harmonic Imaging	Yes
Relative Humidity	30% to 85% (non-condensing)
Imaging Modes	Color Doppler, Power Doppler
Power Supply	100-240 V~ 50/60 Hz
Probe Connectors	2 active probe connectors
Probe Types	Convex, Linear, Phased Array
Operating Temperature	10°C to 40°C
Storage Temperature	-20°C to +55°C
Transducer Ports	2
