Mindray DC-30

System Installation 3-13
3.4.3 Installing Printer Adapter
 Overview
No.
Name
Function
1.
Power Button
Powers on the printer adapter.
2.
USB port
Connects the printer to the printer adapter.
3.
Network port
Connects the printer adapter to the Ultrasound
system.
4.
Power inlet
Connects the printer adapter to power by using the
auxiliary output port of the Ultrasound system.
 Specification
 Power Supply
Input:
100-240 V~@0.6A
Frequency:
50/60Hz
Output:
12VDC@2.08A
3
4
1
2
