Mindray DC-30

2-8 Specifications
2.2 Specifications
2.2.1 Dimensions and Weight
 Size:
670mm×520mm×(1265~1415)mm (Depth×Width×Height) (Adjustable control panel is
configured)
670mm×520mm×1315mm (Depth×Width×Height) (Standard configuration)
 Net Weight: ≤55kg (including one battery)
2.2.2 Electrical Specifications
2.2.2.1 AC Input
2.2.2.2 Battery (optional)
2.2.3 Environmental Conditions
Warning ：
Do not use this system in the conditions other than those
specified
2.2.4 Monitor Specification
Voltage
220-240V~,100-127V~
Frequency
50/60Hz
Power consumption
420VA
Direct Current
14.8V
Capacity
6600mAh
Operating conditions
Storage and transportation
conditions
Ambient temperature
0℃～40℃
-20℃～55℃
Relative humidity
30%～85% (no
condensation)
20%～95% (no condensation)
Atmospheric
pressure
700hPa～1060hPa
700hPa～1060hPa
Voltage
12V
Dimension
15-inch/17-inch LCD
Resolution
1024 × 768 (15-inch); 1280×1024(17-inch)
Visible angle
140 degrees (15-inch); 178 degrees (17-inch)
