Mindray DC-30 Service Manual

6-10 Software installation and Maintenance
6.6.2 Log Maintenance
6.6.2.1 Export the Log
1. Connect the USB disk.
2. Click [Export Log] on the Maintenance menu.
3. Select the path in the Browse page to save the log, and click [OK].
4. When the log is exported, the system prompts “Export succeed!” click [OK] to
return to the Maintenance menu.
NOTE:
The log can be exported to the external USB storage device only, make sure
the connection between U disk and ultrasound is normal before the
exporting.

Mindray DC-30 Specifications

General

DICOM	Yes
Hard Drive	500 GB
Continuous Wave Doppler	Yes
Tissue Harmonic Imaging	Yes
Relative Humidity	30% to 85% (non-condensing)
Imaging Modes	Color Doppler, Power Doppler
Power Supply	100-240 V~ 50/60 Hz
Probe Connectors	2 active probe connectors
Probe Types	Convex, Linear, Phased Array
Operating Temperature	10°C to 40°C
Storage Temperature	-20°C to +55°C
Transducer Ports	2
