Mindray DC-30 Service Manual

System Installation 3-3
3.2 Unpacking
Tool: scissors
Installation duration: 2 persons, ten minutes.
3.2.1 Unpacking
3.2.1.1 Unpacking Sketch
Figure 1 Main unit package drawing
LARIS control
panel protecting
foam
Probe case
LCD protecting
foam
POLARIS LCD
protecting foam
Package (480 X 340 X 135)
CS05 main unit
protecting foam
POLARIS bottom
supporting foam
DP-5 series close
carton
CS05 wooden
cover
CS05 pallet

Mindray DC-30 Specifications

General

DICOM	Yes
Hard Drive	500 GB
Continuous Wave Doppler	Yes
Tissue Harmonic Imaging	Yes
Relative Humidity	30% to 85% (non-condensing)
Imaging Modes	Color Doppler, Power Doppler
Power Supply	100-240 V~ 50/60 Hz
Probe Connectors	2 active probe connectors
Probe Types	Convex, Linear, Phased Array
Operating Temperature	10°C to 40°C
Storage Temperature	-20°C to +55°C
Transducer Ports	2
