Mindray DC-30 Service Manual

2-6 Specifications
No.
Name
Description
Function
<25>.
Arrow
/
/ Press to enter or exit the arrow comment status.
<26>.
Clear
/
Press to clear the comments or measurement
calipers on the screen.
<27>.
Scale
/
Press to adjust image parameter of Scale.
<28>.
Baseline
/
Press to adjust image parameter of Baseline.
<29>.
Menu Nav.
/
Press to adjust image parameters.
<30>.
/
Multifunctional
Knob
Adjusts the image parameter combed with the
key of Scale/Baseline/Menu.
<31>.
3D/4D
/
Press to enter 3D/4D mode.
<32>.
PW
/
Press to enter PW mode.
<33>.
Color
/
Press to enter Color mode.
<34>.
M
/
Press to enter M mode.
<35>.
B
/
Press to enter B mode.
<36>.
Measure
/
Press to enter/ exit Application Measurement
status.
<37>.
Update
/
Measurement status: press to switch between
the fixed and active end of the caliper;
Multi-imaging mode: press to change the
currently active window.
iScape/Smart 3D: press to start/stop image
acquisition.
<38>.
Caliper
/
Press to enter/ exit General Measurement.
<39>.
Curosr
/
Press to show or hide the cursor.
<40>.
Set
/
Press to confirm an operation, same as the
left-button of a mouse.
<41>.
/
Trackball
You can roll the trackball to change the cursor
position.
<42>.
Gain/
iTouch
/
Rotate to adjust the gain;
Press to enter/ exit iTouch.
<43>.
Freeze
/
Press to freeze or unfreeze the image.
<44>.
TGC
/
Move to adjust time gain compensation.
<45>.
Focus
Freq./THI
/
Press to switch between Focus and Freq./THI;
Rotate to adjust corresponding parameter.
<46>.
Depth
Zoom
/
Press to switch between Depth and Zoom;
Rotate to adjust corresponding parameter.
<47>.
Save 1
/
Press to save, user-defined key.
<48>.
Save 2
/
Press to save, user-defined key.
<49>.
Print
/
Press to print: user-defined key.
<50>.
Comment
/
Press to enter comment status.

Mindray DC-30 Specifications

General

DICOM	Yes
Hard Drive	500 GB
Continuous Wave Doppler	Yes
Tissue Harmonic Imaging	Yes
Relative Humidity	30% to 85% (non-condensing)
Imaging Modes	Color Doppler, Power Doppler
Power Supply	100-240 V~ 50/60 Hz
Probe Connectors	2 active probe connectors
Probe Types	Convex, Linear, Phased Array
Operating Temperature	10°C to 40°C
Storage Temperature	-20°C to +55°C
Transducer Ports	2
