4 Setup
Operator’s Manual 4 - 13
MLDAP Privilege Management
Turn on the access control function and log in to the system as Administrator before you edit
privileges for the MLDAP (Mindray Lightweight Directory Access Protocol) users.
Tap [MLDAP Config]:
Member of filter/Privilege • Enter the member name, and select or deselect privileges from the
drop-down list of “Privilege”.
• Click [Add], and the new members and privileges will appear in
the Member of filter list.
• Select a member to be deleted, and click [Delete].
• Select a member to be modified, modify the member name, and
select or deselect privileges from the drop-down list of
“Privilege”. Click [Modify], and the modified member name and
privileges will appear in the Member of filter list.
Logon Test 1. Enter the User name and password in the field boxes of the
Authentication test area.
2. Click [Logon Test] to test whether the user is authenticated.
User field name Select [Use user field name] to customize the user field name. After
that, the members and privileges cannot be edited.
Enter the user field name in the field box of the “User field name”
(the user field names are configured in the LDAP server. For details,
please refer to the LDAP server manual).
The user field name corresponding to privileges are as follows:
• iStation Access: 1
• Save Exam: 2
• Export Exam: 4
• Network Settings: 8
• Maintenance Menus: 16
• System Settings: 32
• Workflow Settings: 64
• Worklist Access: 128
NOTE:
The privilege items can be combined randomly. For example, if
user A is assigned with all the above 8 privileges, the user field
name for user A is 1+2+4+8+16+32+64+128=255.
Item Description
Item Description
Service Address Enter the server address in the field box after accessing the network.
Port Enter the port of the server.
Default Domain Configuration is not required when logs on the MLDAP server.
Configuration is required for other servers when logs on another
server.
