Revision:1.0(2023–5–17)
22
No. Name Function
5
Charging cable plug Connects to the charging port of the probe.
6 Charging USB port Connects to an external USB power adapter.
7
Multifunctional key Allows for function setting.
8 Ultrasound
transmitting head
Converts electric signals to ultrasound signals and
concentrates sound beams in the specified direction;
receives ultrasound signals and converts them to
electric signals. The lens on the surface of the probe is
an acoustic lens. Apply ultrasonic gel to the surface of
the acoustic lens before an examination.
2.2 Specifications
2.2.1 Physical Specifications
Dimensions: 46.5 mm x 32 mm x 175 mm
Weight: ≤ 270 g (probe)
2.2.2 Electrical Specifications
Input voltage: 5 V or 9 V
Input current: 3 A (max.)
Battery: 3.85 V DC, 1600 mAh
2.2.3 Environmental Specifications
• Operating environment
Temperature: 0°C to 35°C
Relative humidity: 20% to 85% (non-condensing)
Atmospheric pressure: 700 hPa to 1060 hPa
• Storage and transportation environment
Temperature: -20°C to 45°C
Relative humidity: 20% to 85% (non-condensing)
Diagnostic Ultrasound System
Service Manual
2 Product Knowledge
