Revision:1.0(2023–5–17)
29
the probe is being charged, the three segments of the ring indicator blink white in sequence to
indicate the charging progress, and the lightning flash status indicator in the ring stays white to
indicate the charging state.
• Network connection indicator: The indicator blinks white when probe is connecting to the
network and stays white after the probe connects to the network successfully.
2.4 Probes and Needle Guides
2.4.1 Probes
Table 2–1
Probes
Image Model
Information
Remarks
i3P Probe type Phased array
Applicable
needle guide
None
i3PA Probe type Phased array
Applicable
needle guide
None
Diagnostic Ultrasound System
Service Manual
2 Product Knowledge
