8 Appendix
8.1 Phantom Usage Illustration
NOTE: Phantoms are optional and can be skipped in periodic maintenance. Phantoms can be
incorporated in the scheduled quality assurance test.
The optimal storage and operating temperatures for phantoms range from 10°C
to 35°C. Do not use phantoms beyond this range, as doing so will compromise
the measured performance indicators.
1. Do not exert force when placing the probe on the acoustic window; otherwise,
the acoustic window and TM materials will be damaged.
2. Do not drop or fiercely bump phantoms. Place phantoms upright and do not put
the upside down unless in maintenance conditions.
KS107BD ultrasound phantom
A1-A5: Axial-lateral resolution target groups
B: Dead zone target group
C: Vertical target group
