History Dialog Common Functions History Dialogs
21 - 22 V Series Operating Instructions
21.5.9 Printing from the Historical Dialogs
The Print dialog is available from the all of the historical dialogs. Up to 24 hours of trends, events, and
full disclosure data may be printed, and up to 12 hours of graphic trends data may be printed.
To print the historical data contained in these historical dialogs:
NOTE: Refer to the "Reports" on page 20-1 for a full description of the reports
and sample reports.
1. Select the Print button from the applicable History dialog tab.
The Print dialog displays (as shown in FIGURE 21-11 and FIGURE 21-12).
2. Select an interval. The potential choices are Current, 1 hr, 2 hrs, 4 hrs, 8 hrs, 12 hrs, 24 hrs,
Tagged, and Archived. Refer to TABLE 21-8 for additional information.
FIGURE 21-11 Example Display Interval
Dialog (Events - List View)
FIGURE 21-12 Example Print Dialog
(Graphic Trends)
TABLE 21-8
TIME INTERVAL PRINTS
Current Page Only prints the four displayed events in the dialog including the
digital parameter values associated with the events.
Current Prints the displayed time period of patient data.
1 hr Prints one hour of patient data, beginning at 1/2 before the
cursor time and printing up to and including the cursor time.
2 hrs Prints two hours of patient data, beginning at one hour before
the cursor time and printing up to and including the cursor
time.
4 hrs Prints four hours of patient data, beginning at two hours before
the cursor time and printing up to and including the cursor
time.
