Alarm Watch Notification Alarm Watch
23 - 6 V Series Operating Instructions
23.3 Alarm Watch Notification
When a watched bed is in alarm, it is either displayed in the A-W tile or displayed somewhere on the
Main Screen (as shown in FIGURE 23-5). Both types of alarm notifications display the alarm type, flash
in the corresponding alarm priority color, and indicate the alarms location. The V 12/V 21 displays the
three highest priority most recent alarms for the currently monitored beds. When there are more
than three active alarms for the currently monitored beds, the Show All (as shown in FIGURE 23-4)
button displays in the tile indicating that there are more than three beds in alarm.
NOTE: If the Host monitor is in the Privacy Mode and a watched bed goes into
alarm, the Privacy Mode indicator/alarm light settings of the Host
monitor are observed. Refer to "Privacy Mode" on page 3-17 for
additional information.
NOTE: If the C.O. Run, PAWP, PA Insertion, Hemo Calculations, Drug
Calculations, or VAccess dialogs is open when a watched bed goes into
alarm, all alarm watch notifications are disabled and the message
“Incoming Alarms Blocked” displays in the A-W tile message area.
A-W Tile Configured
FIGURE 23-3 Example Alarm Watch Tile (One (1) Bed in Alarm)
FIGURE 23-4 Example Alarm Watch Tile (Three (3) or More Beds in Alarm)
A-W Tile Not-Configured
FIGURE 23-5 Example Alarm Watch Notification Strip (Three alarms)
