Chapter 2 Machine Overview
2-9
Mx400(400S) Interior Parts
REAR
RIGHT
① ⑤ ④ ③
FRONT
① Head Assembly(6 Module+6Module)
② Conveyer Assembly: Dual Conveyor (410x250,410x460mm)
Mx400S : Single Conveyor (410x460mm)
③ M-ANC Assembly
④ FOV24 Standard Camera Assembly
⑤ Feeder Base Assembly
LEFT
①
②
④
⑤
IN
OUT
③
