Chapter 4 Regular Chec4k- 4-27
grease, etc.
Malfunction of the X-Y
Gantry could be caused.
3) Two selaings are
attached to both ends of
the Linear Slide Block. If
the machine is operated
just after greasing the X-
axis Linear Slide, part of
the grease could drop on
the floor. Therefore, wipe
out part of the grease
after greasing.
<X-Gantry> Greasing
Greasing
