Chapter 5 Solutions for Errors 5-
25
12006
Air pressure is too low.
This error occurs when the air
pressure of the machine is low.
Check the air pressure.
5-40
12007
XY-Gantry motion is
impossible as the Z-axis is
too low.
Check the height of Z-axis.
Check the Z-axis height setting.
12008
Front feeder floating is not
detected.
Not applicable to Mx Series
12009
Rear feeder floating is not
detected.
Not applicable to Mx Series
12010
No pallet is detected at the
specified position or sensor
error
Check the pallet of Tray Feeder
or Shuttle.
12011
The front vacuum tank
pressure is too low.
Not applicable to Mx Series
5-40
12012
The rear vacuum tank
pressure is too low.
Not applicable to Mx Series
5-40
12013
The linear motor
temperature is too high.
Not applicable.
12014
The front feeder base is not
locked.
Not applicable to Mx Series
12015
The rear feeder base is not
locked.
Not applicable to Mx Series
12016
Chips probably missing on
the reproduced board
Check the component database
and the operation status.
12020 -
12027
The nozzles of Front Gantry
Head 16 are stained with
foreign materials or chips
are detected at the nozzles
after placement.
Check the nozzle.
Carry out cleaning and
maintenance referring to the
nozzle check procedure.
Error Code
Message Description
Actions
References
12030 -
12037
The nozzles of Rear
Gantry Head 1-6 are
stained with foreign
materials or chips are
detected at the nozzles
after placement.
Check the nozzle.
Carry out cleaning and maintenance
referring to the nozzle check
procedure.
13000 -
13007
Error occurred while
the nozzles (Front
Gantry Head 1- 6)
were placing chips
Check the setting and operation
status of ANC.
13010 -
13017
Error occurred while
the nozzles (Rear
Gantry Head 1- 6) were
placing chips
Check the setting and operation
status of ANC.
