1-2 TF5 Manual (Tray Feeder Operation Manual)
Setup Environment
The tray feeder is attached to the main frame of the Mx-Series
system Check where the tray feeder will be mounted.
The figure below show where to install the tray feeder.
(The main frame below shows the Mx-Series main frame)
1. Floor
The machine should be installed on a rigid floor that doesn’t vibrate.
The floor should be kept as horizontal as possible.
2. Temperature
15℃∼ ℃ 18
3. Humidity
30% ∼ 75%
It is recommended that humidity is maintained at below 45% to
prevent moisture from forming on the machine.
▶ A: Locking hole for Mx-Series
▶ B: Locking hole for MPS-1025P, 1020P, 1020QP and Mx-
110P/110TP
<Figure 1-1ᆞ Clamping Base mounting position>
