Chapter 1. Machine Setup 1-
5
Setup Procedure
1. Attach the Clamping Base to main frame.
2. Slowly insert the Tray Feeder into the Clamping Base.
<
Figure
1-3
Tray Feeder Connectors>
TFU-PWR
TFU-SIG
TFU-AIR
