1-4 TF5 Manual (Tray Feeder Operation Manual)
<Figure 1-2ᆞ Tray Feeder attached to the Mx-Series Main Frame>
2) After mounting the tray feeder on the Mx-Series main frame, connect the
harness cable between the Mx-Series system and the tray feeder.
TFU – PWR: Tray feeder power cable
TFU – SIG: Tray feeder signal cable
TFU – AIR: Tray feeder air cable
(The figure below shows the connectors to connect the Mx-Series
harness to the tray feeder.)
For Mx-Series, Mx-110P/TP,Mx-240,MPS-
1020QP
To Next Page
